AD8370AREZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1206196
Category:
Amplifier, Buffer IC
Package:
TSSOP-16
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8370AREZ Programmable/Variable Amplifier, 1Channels, 1 Amplifier, 750MHz, -40℃, 85℃, 3V to 5.5V
Stock Locations:
Availability:
929 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 18.62

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8370AREZ is a digitally controlled Variable Gain Amplifier (VGA) provides precision gain control, high IP3 and low noise figure. The excellent distortion performance and wide bandwidth make the AD8370 a suitable gain control device for modern receiver designs. For wide input, dynamic range applications, the AD8370 provides two input ranges - high gain mode and low gain mode. A vernier, 7-bit, transconductance (gm) stage provides 28dB of gain range at better than 2dB resolution and 22dB of gain range at better than 1dB resolution. A second gain range, 17dB higher than the first, can be selected to provide improved noise performance. The AD8370 is powered on by applying the appropriate logic level to the PWUP pin. When powered down, the AD8370 consumes less than 4mA and offers excellent input to output isolation. The gain setting is preserved when operating in a power-down mode.
Programmable low and high gain (<2 dB resolution)
Serial 8-bit digital interface
Wide input dynamic range
Power-down
7dB Noise figure at maximum gain

Show

AD8370AREZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	TSSOP-16
Supply Current	79 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	16 Position
Power Dissipation	0.575 W
Common Mode Rejection Ratio	77 dB
Bandwidth	750 MHz
Slew Rate	5.75 kV/μs
Gain	34.0 dB
Input Bias Current	400 pA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	750 MHz
Power Dissipation (Max)	575 mW
Minimum CMRR Range	77 dB
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5V ~ 7V
Supply Voltage (Min)	3 V
	Show
Size-Length	5 mm
Size-Width	4.4 mm
Size-Height	1 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
