ADAS3023BCPZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC3598012
Category:
Analog to Digital, ADC IC
Package:
LFCSP-40
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADAS3023BCPZ Analog to Digital Converter, 16Bit, 125KSPS, Single, 4.75V, 5.25V, LFCSP
Stock Locations:
Availability:
263 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 26.5

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADAS3023BCPZ is a 16-bit complete simultaneous sampling successive approximation-based analog-to-digital Data Acquisition System. This system is capable of simultaneously sampling up to 125kSPS for 8-channel manufactured on the Analog Devices Inc, proprietary iCMOS® high voltage industrial process technology. The converter integrates 8-channel of low leakage track and hold, a programmable gain instrumentation amplifier stage with a high common-mode rejection offering four differential input ranges, a precision low drift 4.096V reference and buffer and a 16-bit charge redistribution successive approximation register analog-to-digital converter. It can resolve differential input ranges of up to ±20.48V when using ±15V supplies. It simplifies design challenges by eliminating signal buffering, level shifting, amplification and attenuation, common-mode rejection, settling time or any of the other analog signal conditioning challenges yet allows for smaller form factor.
Ease-of-use
High impedance 8-channel input - >500MR
High input common-mode rejection - 95dB
User-programmable input ranges
No latency/pipeline delay
Serial 4-wire 1.8 to 5V SPI/SPORT-compatible interface

Show

ADAS3023BCPZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	40 Pin
Case/Package	LFCSP-40
Supply Voltage (DC)	4.75V (min)
Supply Current	16 mA
Number of Channels	1 Channel
Number of Positions	40 Position
Number of Bits	16 Bit
Power Dissipation	2000 W
Sample Rate	500 ksps
Resolution (Bits)	16.0 Bit
Input Impedance	500 MΩ
Number of ADCs	1 ADC
Number of Inputs	8 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	1 DAC
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	4.75 V
	Show
Size-Length	6.1 mm
Size-Width	6.1 mm
Size-Height	0.95 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
