ADG419BNZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC145883
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
DIP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADG419BNZ Analog Switch, Single Channel, SPDT, 1Channels, 35Ω, 4.5V to 5.5V, DIP, 8Pins
Stock Locations:
Availability:
283 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 2.34

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADG419BNZ is a LC²MOS Precision Mini-DIP Analogue Switch designed on an enhanced LC²MOS process that provides low power dissipation yet gives high switching speed, low on resistance and low leakage currents. The on resistance profile is very flat over the full analogue input range, ensuring excellent linearity and low distortion. The part also exhibits high switching speed and high signal bandwidth. CMOS construction ensures ultralow power dissipation, making the parts ideally suited for portable and battery-powered instruments. Each switch of the ADG419 conducts equally well in both directions when on and has an input signal range that extends to the supplies. In the off condition, signal levels up to the supplies are blocked. This exhibits break-before-make switching action.
44V Supply maximum rating
VSS to VDD analogue signal range
Ultralow power dissipation (<35µW)
Fast transition time (160ns maximum)
Break-before-make switching action
ESD sensitive device, take proper precaution while handling the device.

Show

ADG419BNZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Number of Outputs	2 Output
Contacts Type	SPDT
Supply Current	100 pA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Drain to Source Resistance (on) (Rds)	25.0 mΩ
Number of Bits	1 Bit
Power Dissipation	0.4 W
Number of Inputs	1 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	400 mW
Supply Voltage	13.5V ~ 16.5V
	Show
Size-Length	9.27 mm
Size-Width	7.24 mm
Size-Height	3.43 mm
Operating Temperature	-40℃ ~ 125℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
