ADT75ARZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC446887
Category:
Temperature Sensor
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADT75ARZ Temperature Sensor IC, Digital, ± 2℃, -55℃, +125℃, SOIC, 8Pins
Stock Locations:
Availability:
9,086 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.29

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADT75 series 12-bit Digital Temperature Monitoring System containing a band gap temperature sensor and a 12-bit analogue-to-digital converter (ADC) to monitor and digitize the temperature to a resolution of 0.0625°C. The ADT75 is pin and register compatible with the LM75 and AD7416. The ADT75 is a shutdown mode that powers down the device and this mode gives a shutdown current of typically 3µA. The A0, A1 and A2 pins are available for address selection. The OS/ALERT pin is an open-drain output that becomes active when temperature exceeds a programmable limit. The OS/ALERT pin can operate in either comparator or interrupt mode. On-chip temperature sensor allows an accurate measurement of the ambient temperature.
Over-temperature indicator
Shutdown mode for low power consumption
Power consumption 79µW typically at 3.3V

Show

ADT75ARZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	3.00V (min)
Output Voltage	2.10 V
Output Current	1.00 mA
Supply Current	0.525 mA
Number of Positions	8 Position
Number of Bits	12 Bit
Power Dissipation	0.7986 mW
Resolution (Bits)	12.0 Bit
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	0.7986 mW
Accuracy	±2 ℃
Supply Voltage	2.7V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
