ADUM5000ARWZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC373287
Category:
Interface Isolator, Digital Isolator
Package:
SOIC-16
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADUM5000ARWZ Digital Isolator, 1Channel, 2.7V, 5.5V, WSOIC, 16Pins
Stock Locations:
Availability:
399 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.68

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADUM5000ARWZ is an Isolated DC-to-DC Converter based on the Analogue Devices, Inc., iCoupler® technology. In this device provides regulated, isolated power in several combinations of input and output voltages. The Analogue Devices chip scale transformer, iCoupler technology, transfers isolated power in this DC-to-DC Converter with up to 33% efficiency. The result is a small form factor, total isolation solution. isoPower uses high frequency switching elements to transfer power through its transformer. Special care must be taken during printed circuit board (PCB) layout to meet emissions standards.
Regulated 3.3 or 5V output
Up to 500mW output power
Thermal overload protection
Product features patented or proprietary protection circuitry, damage may occur on devices subjected to high energy ESD.

Show

ADUM5000ARWZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	2.70V (min)
Operating Voltage	2.7V ~ 5.5V
Power Rating	330 mW
Number of Outputs	1 Output
Output Voltage	5 V
Output Current	100 mA
Supply Current	4.00 mA
Number of Channels	1 Channel
Number of Positions	16 Position
Output Power	500 mW
Isolation Voltage	2.5 kV
Switching Frequency	180 MHz
Input Voltage (Max)	5.5 V
Input Voltage (Min)	2.7 V
Output Voltage (Max)	5.5 V
Output Voltage (Min)	3.3 V
Output Current (Max)	100 mA
Input Power (Max)	0.5 W
Input Power (Max)	500 mW
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
Input Voltage	3V ~ 5.5V
	Show
Size-Length	10.5 mm
Size-Width	7.6 mm
Size-Height	2.35 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
