Description

The AQW210EH is a Solid State Relay with DPST-NO contacts and through hole terminals. This AQW-series PhotoMOS GU-E relay feature extremely low closed-circuit offset voltage to enable control of low-level analogue signals without distortion. Applicable for 2-form-A use as well as two independent 1-form-A use.
Controls low-level analogue signals
High sensitivity, high speed response
Low-level off state leakage current
5000V Reinforced isolation
850mW Power dissipation
2ms Turn-on and 1ms turn-off maximum time
-40 to 85°C Operating temperature range

Show

AQW210EH Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Current Rating	120 mA
Insulation Resistance	1.00 GΩ
Capacitance	1.5 pF
Power Rating	850 mW
Output Voltage	0V ~ 350V
Output Current	120 mA
Contacts Type	DPST-NO
Load Current	120 mA
Input Current	50 mA
Resistance	23.0 Ω
Rise Time	500 µs
Isolation Voltage	5 kV
Forward Current	1.2 mA
Input Voltage (Max)	1.5 V
Output Voltage (Max)	350 V
Output Current (Max)	0.12 A
Input Current (Min)	50 mA
Load Current (Max)	120 mA
Load Current (Min)	0.12 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating	350 VAC
Input Voltage	1.14 VDC
	Show
Size-Length	9.86 mm
Size-Width	6.40 mm
Size-Height	3.2 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
