Description

The BAV70M3T5G Common Cathode Switching Diode is a spin-off of our popular SOT-23 three-leaded device. It is designed for switching applications and is housed in the SOT-723 surface mount package. This device is ideal for low-power surface mount applications, where board space is at a premium.

Show

BAV70M3T5G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-723-3
Halogen Free Status	Halogen Free
Number of Positions	3 Position
Forward Voltage	1.25 V
Power Dissipation	640 mW
Reverse recovery time	6 ns
Max Repetitive Reverse Voltage (Vrrm)	100V
Forward Current	200 mA
Max Forward Surge Current (Ifsm)	500 mA
Max Reverse Leakage Current (Ir)	2.5uA
Maximum Forward Voltage (Max)	1.25V @150mA
Forward Current (Max)	0.2 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	640 mW
	Show
Size-Length	1.25 mm
Size-Width	0.85 mm
Size-Height	0.55 mm
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
Minimum Packing Quantity	8000
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
