BQ76PL536ATPAPTQ1 - TI
Manufacturer:
TI
ManyChip's Part#:
MC25138522
Category:
Battery Management IC
Package:
HTQFP-64
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS BQ76PL536ATPAPTQ1 Li-Ion Battery Over/Under Voltage Protector, 3/4/5/6 Series, 7.2V to 27V supply, HTQFP-64
Stock Locations:
Availability:
253 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 7.15

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The BQ76PL536ATPAPTQ1 is a cell Li-ion Battery Monitor and Secondary Protection IC for EV and HEV applications. It incorporates a precision analog-to-digital converter (ADC); independent cell voltage and temperature protection; cell balancing and a precision 5V regulator to power user circuitry. It integrates a voltage translation and precision analog-to-digital converter system to measure battery cell voltages with high accuracy and speed. The BQ76PL536A-Q1 provides full protection (secondary protection) for overvoltage, under voltage and over temperature conditions. When safety thresholds are exceeded, the BQ76PL536A-Q1 sets the FAULT output. No external components are needed to configure or enable the protection features. Cell voltage and temperature protection functions are independent of the ADC system.
Hot-pluggable
High-speed SPI for data communications
Stackable vertical interface No isolation components required between ICs
Configuration data stored in ECC-OTP registers
Over and undervoltage protection
Overtemperature protection
Programmable thresholds and delay times
Green product and no Sb/Br
Device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.

Show

BQ76PL536ATPAPTQ1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	64 Pin
Case/Package	HTQFP-64
Supply Voltage (DC)	7.20V (min)
Output Voltage	5 V
Number of Positions	64 Position
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	7.2V ~ 27V
Supply Voltage (Max)	27 V
Supply Voltage (Min)	7.2 V
	Show
Operating Temperature	-40℃ ~ 105℃ (TA)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
