BTS500851TMBAKSA1 - Infineon
Manufacturer:
Infineon
ManyChip's Part#:
MC1248704
Category:
Power Distribution
Package:
TO-220
Datasheet:
Datasheet 3D Model
Description:
Power Switch Hi Side 1Out 9.9A 0.0072Ω Automotive 7Pin(7+Tab) TO-220 Tube
Stock Locations:
Availability:
545 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 39.91

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The BTS50085-1TMB is a high side Power Switch N channel vertical power FET with charge pump, current controlled input and diagnostic feedback with load current sense, integrated in Smart SIPMOS® chip on chip technology. Providing embedded protection and diagnostic functions.
Overload protection
Current limitation
Short-circuit protection
Over temperature protection
Over voltage protection (including load dump)
Clamp of negative voltage at output
Low ohmic inverse current operation
Diagnostic feedback with load current sense
Open load detection via current sense
Green product
Loss of Vbb protection
AEC qualified
High load current capability
High inrush current capability
Very high energy capability
Capable for 24V applications
Integrated protection functionality
Integrated diagnosis functionality

Show

BTS500851TMBAKSA1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	7 Pin
Case/Package	TO-220
Number of Outputs	1 Output
Output Current	9.9 A
Supply Current	0.8 mA
Number of Positions	7 Position
Power Dissipation	170 W
Number of Inputs	1 Input
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	170000 mW
Input Voltage	58 V
	Show
Size-Length	10 mm
Size-Width	9.25 mm
Size-Height	4.4 mm
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
