Description

The CC1120RHBT is a low-power high-performance RF Transceiver for narrowband systems designed for high performance at very low-power and low-voltage operation in wireless systems. All filters are integrated, thus removing the need for costly external SAW and IF filters. The Short Range Device (SRD) frequency bands at 164 to 192MHz, 274 to 320MHz, 410 to 480MHz and 820 to 960MHz. The CC1120 device provides extensive hardware support for packet handling, data buffering, burst transmissions, clear channel assessment, link quality indication and wake-on-radio. The main operating parameters of the transceiver can be controlled through an SPI interface. In a typical system, the transceiver is used with a microcontroller and only a few external passive components.
Enhanced Wake-On-Radio (eWOR) functionality for automatic low-power receive polling
Includes functions for antenna diversity support
Support for retransmissions
Support for automatic acknowledge of received packets
TCXO support and control, also in power modes
Automatic Clear Channel Assessment (CCA) for Listen-Before-Talk (LBT) systems
Built-in coding gain support for increased range and robustness
Digital RSSI measurement
Temperature sensor
Automatic output power ramping
Green product and no Sb/Br
ESD sensitive device, take proper precaution while handling the device.

Show

CC1120RHBT Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	32 Pin
Case/Package	VQFN-32
Frequency	164MHz ~ 192MHz,274MHz ~ 320MHz,410MHz ~ 480MHz,820MHz ~ 960MHz
Supply Voltage (DC)	2.00V (min)
Number of Positions	32 Position
Data Rate	200 kbps
FLASH Memory Size	0 B
Output Power	16 dBm
Standby Current	300 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	2 V
	Show
Size-Length	5.15 mm
Size-Width	5.15 mm
Size-Height	0.95 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
