Image is for your reference only,please check specifications for details

CPF0402B1K0E1 - TE Connectivity
Manufacturer:
TE Connectivity
ManyChip's Part#:
MC55811770
Category:
Chip SMD Resistor
Package:
0402
Datasheet:
Datasheet 3D Model
Description:
TE CONNECTIVITY / NEOHM CPF0402B1K0E1 SMD Chip Resistor, Thin Film, 1KΩ, 25V, 0402 [1005 Metric], 0.063W(1/16W), ± 0.1%, CPF Series
Stock Locations:
Availability:
3,378 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.24

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TE Connectivity CPF series are high stability, thin film precision chip resistors. The Resistance range includes E24 and E96 decade values from 1ohm to 4Mohm. These resistors offer various power dissipations relating to chip size and are suitable for all applications where close accuracy and stability are essential. CPF series thin film precision resistors have accurate and uniform physical dimensions to facilitate placement.
EIA 0201, 0402, 0603, 0805, 1206, 1210, 2010, 2512 chip sizes available
Temperature coefficient is 15ppm/°C, 25ppm/°C and 50ppm/°C
±0.1%, ±0.5% and ±1% tolerance
Electroplated 100% matte Sn finish
Operating temperature range -55°C to 125°C

Show

CPF0402B1K0E1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package (SI)	1005
Case/Package	0402
Voltage Rating (DC)	50.0 V
Capacitance Tolerance	±0.1 %
Power Rating	0.063 W
Part Family	CPF
Resistance	1 kΩ
Resistance Tolerance	±0.1 %
Operating Temperature (Max)	155 ℃
Operating Temperature (Min)	-55 ℃
Voltage Rating	25 V
Operating Voltage (Max)	25 V
	Show
Size-Length	1 mm
Size-Width	0.5 mm
Size-Height	0.35 mm
Operating Temperature	-55℃ ~ 155℃
Temperature Coefficient	±25 ppm/℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
Minimum Packing Quantity	10000
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ELV Compliant	Compliant
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
