Description
- The ELL6RH100M is a surface mount Choke Coil with higher reliability in mounting by separated user terminal and internal connection. This shielded choke supports 100kHz test frequency and ±10% inductance tolerance.
- Large current capability
ELL6RH100M Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 2 Pin |
| Case/Package | 6.4mm x 6mm x 2.8mm |
| Current Rating | 1.1 A |
| Capacitance Tolerance | ±20 % |
| Inductance | 10 µH |
| Part Family | ELL6RH |
| Resistance | 95.0 mΩ |
| Resistance Tolerance | ±20 % |
| Shielding | Yes |
| Inductance Tolerance | ±20 % |
| Test Frequency | 100 kHz |
| DC Resistance (DCR) | 95 mΩ |
| Operating Temperature (Max) | 105 ℃ |
| Resistance (DC Max) | 0.095 Ω |
| Show | |
| Size-Length | 6.4 mm |
| Size-Width | 6.00 mm |
| Size-Height | 2.8 mm |
| Product Lifecycle Status | Unknown |
| Packaging | Cut Tape (CT) |
| Minimum Packing Quantity | 1000 |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
