HMC814 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC3111688
Category:
RF Module, IC, Accessory
Package:
Die
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES HMC814 RF Frequency Multiplier IC, Single 5V/88mA, 13GHz to 24.6GHz, HQFN-12
Stock Locations:
Availability:
249 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 84.84

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

High Output Power: +17 dBm Low Input Power Drive: 0 to +6 dBm Fo Isolation: >20 dBc @ Fout = 19 GHz 100 kHz SSB Phase Noise: -136 dBc/Hz Single Supply: +5V @ 88mA Die Size: 1.2 x 1.23 x 0.1 mm

Show

HMC814 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Number of Pins	4 Pin
Case/Package	Die
Frequency	13GHz ~ 24.6GHz
Supply Voltage (DC)	4.50V (min)
Power Dissipation	782 mW
Output Power	17 dBm
Input Power (Max)	6 dBm
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	782 mW
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	Show
Operating Temperature	-55℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance Edition	2015/12/17
