Description

The IPG20N04S4L-08 is an OptiMOS™-T2 dual N-channel enhancement-mode Power Transistor for small loads control switching and body applications.
Logic level
Green device
100% Avalanche tested
Larger source lead-frame connection for wire bonding
Same thermal and electrical performance as a DPAK with the same die size
Exposed pad provides excellent thermal transfer (varies by die size)

Show

IPG20N04S4L08ATMA1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	PG-TDSON-8-4
Number of Positions	8 Position
Drain to Source Resistance (on) (Rds)	0.0072 Ω
Polarity	Dual N-Channel
Power Dissipation	54 W
Threshold Voltage	1.7 V
Drain to Source Voltage (Vds)	40 V
Continuous Drain Current (Ids)	20A
Rise Time	3 ns
Input Capacitance (Ciss)	2350pF @25V(Vds)
Input Power (Max)	54 W
Fall Time	20 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	54000 mW
	Show
Size-Length	5.15 mm
Size-Width	6.15 mm
Size-Height	1 mm
Operating Temperature	-55℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
