Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 8 Pin |
Case/Package | SOIC-8 |
Supply Voltage (DC) | 10.0V (min) |
Operating Voltage | 10V ~ 20V |
Rise/Fall Time | 100ns, 50ns |
Number of Outputs | 2 Output |
Output Voltage | 10V ~ 20V |
Output Current | 210 mA |
Number of Channels | 2 Channel |
Number of Positions | 8 Position |
Power Dissipation | 0.625 W |
Quiescent Current | 270 µA |
Rise Time | 170 ns |
Fall Time | 90 ns |
Fall Time (Max) | 90 ns |
Fall Time (Max) | 170 ns |
Operating Temperature (Max) | 125 ℃ |
Operating Temperature (Min) | -40 ℃ |
Power Dissipation (Max) | 625 mW |
Supply Voltage | 10V ~ 20V |
Supply Voltage (Max) | 20 V |
Supply Voltage (Min) | 10 V |
Show | |
Size-Length | 5 mm |
Size-Width | 4 mm |
Size-Height | 1.5 mm |
Operating Temperature | -40℃ ~ 150℃ (TJ) |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ECCN Code | EAR99 |
