LM2901D - TI
Manufacturer:
TI
ManyChip's Part#:
MC3473015
Category:
Comparator, Analog Comparator IC
Package:
SOIC-14
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS LM2901D Analog Comparator, Quad, Differential, 4, 300ns, ± 1V to ± 18V, SOIC, 14Pins
Stock Locations:
Availability:
1,025 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.48

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The LM2901D is a Quad Differential Comparator designed to operate from a single power supply over a wide range of voltages. Operation from dual supplies also is possible, as long as the difference between the two supplies is 2 to 36V and VCC is at least 1.5V more positive than the input common-mode voltage. Current drain is independent of the supply voltage. The outputs can be connected to other open-collector outputs to achieve wired-AND relationships.
0.8mA Low supply-current drain independent of supply voltage
Common-mode input voltage range includes ground
±36V Differential input voltage range equal to maximum-rated supply voltage
Low output saturation voltage
Output compatible with TTL, MOS and CMOS
Green product and no Sb/Br

Show

LM2901D Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Supply Voltage (DC)	2.00V (min)
Operating Voltage	2V ~ 36V
Output Current	20 mA
Supply Current	2 mA
Number of Circuits	4 Circuit
Number of Channels	4 Channel
Number of Positions	14 Position
Power Dissipation	830 mW
Quiescent Current	800 µA
Input Offset Voltage	7 mV
Input Bias Current	250 nA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2V ~ 36V
Supply Voltage (Max)	30 V
Supply Voltage (Min)	2 V
	Show
Size-Length	8.65 mm
Size-Width	3.91 mm
Size-Height	1.58 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	ECL99
