Description
- The LQH2MCN100K02L is a 10µH Wirewound Chip Coil/Inductor for DC-DC converter.
- Non magnetic shield
- -40 to 80°C Operating temperature range
LQH2MCN100K02L Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 2 Pin |
| Case/Package | 0806 |
| Current Rating | 225 mA |
| Capacitance Tolerance | ±10 % |
| Inductance | 10 µH |
| Self Resonant Frequency | 48 MHz |
| Part Family | LQH |
| Resistance | 1.20 Ω |
| Resistance Tolerance | ±30 % |
| Resonant Frequency | 48.0 MHz |
| Shielding | No |
| Inductance Tolerance | ±10 % |
| Test Frequency | 1 MHz |
| DC Resistance (DCR) | 1.2 Ω |
| Current Rating (DC) | 225 mA |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Resistance (DC Max) | 1.2 Ω |
| Show | |
| Size-Length | 2 mm |
| Size-Width | 1.6 mm |
| Size-Height | 0.9 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| Minimum Packing Quantity | 3000 |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
