Description
- **Voltage Controlled Oscillators (VCO), ON Semiconductor**
- PLL based Voltage Controlled Oscillators (VCO).
MC14046BDWG Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 16 Pin |
| Case/Package | SOIC-16 |
| Frequency | 1.9 MHz |
| Supply Voltage (DC) | 3.00V (min) |
| Capacitance | 7.5 pF |
| Halogen Free Status | Halogen Free |
| Supply Current | 5.00 mA |
| Number of Circuits | 1 Circuit |
| Power Dissipation | 500 mW |
| Quiescent Current | 20 µA |
| Number of Gates | 1 Gate |
| Duty Cycle | 50 % |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Supply Voltage | 3V ~ 18V |
| Supply Voltage (Max) | 18 V |
| Supply Voltage (Min) | 3 V |
| Show | |
| Size-Length | 10.45 mm |
| Size-Width | 7.6 mm |
| Size-Height | 2.4 mm |
| Operating Temperature | -55℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2015/12/17 |
| ECCN Code | EAR99 |
