Image is for your reference only,please check specifications for details

MC33174D - ST Microelectronics
Manufacturer:
ST Microelectronics
ManyChip's Part#:
MC14661233
Category:
Operational Amplifier, OP Amp IC
Package:
SOIC-14
Datasheet:
Datasheet 3D Model
Description:
STMICROELECTRONICS MC33174D Operational Amplifier, Quad, 4 Amplifier, 2.1MHz, 2V/µs, ± 2V to ± 22V, SOIC, 14Pins
Stock Locations:
Availability:
66 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.83

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The MC33174D is a low power quad bipolar Operational Amplifier offers both low consumption (200µA) and good speed (2.1MHz, 2V/µs). Moreover the input common mode range extends down to the lower supply rail, allowing single supply operation from +4 to +44V.
Wide input common-mode voltage range including VCC-
Pin-to-pin compatible with standard single op-amp
100mV Typical low level output voltage close to VCC-
10µV/°C Input offset voltage drift

Show

MC33174D Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Supply Voltage (DC)	44.0 V
Operating Voltage	3V ~ 44V
Supply Current	220 µA
Number of Circuits	4 Circuit
Number of Channels	4 Channel
Number of Positions	14 Position
Common Mode Rejection Ratio	80 dB
Bandwidth	2.1 MHz
Slew Rate	2.00 V/μs
Gain Bandwidth Product	2.1 MHz
Input Offset Voltage	1 mV
Input Bias Current	20 nA
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	2.1 MHz
Minimum CMRR Range	80 dB
Supply Voltage (Max)	22 V
	Show
Size-Length	8.75 mm
Size-Width	4 mm
Size-Height	1.65 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
