**NPN Power Transistors, ON Semiconductor**
These ON Semiconductor transistors can amplify analog or digital signals. They can also switch DC or function as an oscillator.

Show

MJ14002G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	TO-204
Voltage Rating (DC)	80.0 V
Current Rating	60.0 A
Number of Positions	2 Position
Polarity	NPN
Power Dissipation	300 W
Breakdown Voltage (Collector to Emitter)	80 V
Thermal Resistance	0.584℃/W (RθJC)
Continuous Collector Current	60A
hFE Min	15 @50A, 3V
Input Power (Max)	300 W
DC Current Gain (hFE)	100
Operating Temperature (Max)	200 ℃
Operating Temperature (Min)	-65 ℃
Power Dissipation (Max)	300000 mW
	Show
Size-Length	38.86 mm
Size-Width	26.67 mm
Size-Height	8.51 mm
Material	Silicon
Operating Temperature	-65℃ ~ 200℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
