Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 3 Pin |
Case/Package | TO-252-3 |
Voltage Rating (DC) | -80.0 V |
Current Rating | -8.00 A |
Number of Positions | 3 Position |
Polarity | PNP |
Power Dissipation | 20 W |
Breakdown Voltage (Collector to Emitter) | 80 V |
hFE Min | 40 @4A, 1V |
Input Power (Max) | 20 W |
DC Current Gain (hFE) | 40 |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -55 ℃ |
Power Dissipation (Max) | 20000 mW |
Show | |
Size-Length | 6.6 mm |
Size-Width | 6.2 mm |
Size-Height | 2.4 mm |
Material | Silicon |
Operating Temperature | 150℃ (TJ) |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/12/17 |
ECCN Code | EAR99 |
