Description

The R41 series capacitors from Kemet are automotive grade, radial leaded, class Y2 metalized polypropylene film EMI suppression capacitors. These capacitors are constructed of multilayer metalized paper encapsulated and impregnated in self extinguishing material meeting the requirements of UL94 V-0 standard. It is used as electromagnetic interference (EMI) suppression filter in "line to ground" and "across the line" applications requiring Y2 / X1 safety classification. It is suitable for use in situations where failure of the capacitor could lead to danger of electric shock and not for use in "series with mains" type applications.
Capacitance values ranges from 0.001µF to 1µF
Voltage rating is 300VAC at 50/60Hz
Lead spacing of 10mm to 22.5mm
Available in ±10%, ±20% tolerance
Operating temperature range from -40˚C to 110˚C
ENEC, UL, cUL, CQC approved
100% screening factory test at 5000VDC/2500VAC
Self healing properties
Automotive grade AEC-Q200 qualified

Show

R413N310040M1M Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	Radial, Box
Pin Pitch	22.5 mm
Voltage Rating (DC)	1000 V
Voltage Rating (AC)	300 V
Capacitance	0.1 µF
Capacitance Tolerance	±20 %
Part Family	R41
Operating Temperature (Max)	110 ℃
Operating Temperature (Min)	-40 ℃
	Show
Size-Length	26.5 mm
Size-Width	8.5 mm
Size-Height	17 mm
Lead Length	30 mm
Operating Temperature	-40℃ ~ 110℃
Product Lifecycle Status	Active
Packaging	Bulk
Life (Hours)	1000 h
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
