- RTD14012 - TE Connectivity
-
Manufacturer:TE Connectivity
-
ManyChip's Part#:MC20445171
-
Category:Power Relay
-
Package:DIP
-
Datasheet:Datasheet 3D Model
-
Description:Реле силовое/сигнальное, SPDT, кратковременного действия, ток катушки 0.033 А, напряжение катушки 12 В DC, мощность катушки 400 мВт, ток контакта 20 А, напряжение контакта 24 В DC, монтаж в отверстие вертикальный, RoHS-совместимый
-
Stock Locations:
-
Availability:9,900 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 2.29
Updated at 16/09/2026 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Силовые реле для печатных плат серии RT1 от TE Connectivity представляют собой реле для сквозного монтажа на печатную плату, используемые для общего применения. Эти реле применяются в управлении котлами, таймерах, управлении гаражными воротами, автоматизации POS-терминалов и интерфейсных модулях.
- Конфигурации контактов SPDT или SPST-NO
- Катушки переменного и постоянного тока доступны в зависимости от заказа
- Коммутационная способность 12 А или 16 А при 250 В переменного тока в зависимости от версии
- Изоляция 5 кВ/10 мм между катушкой и контактами
- Температура окружающей среды 85 °C (катушка постоянного тока)
- Версия WG соответствует стандарту IEC 60335-1
- Версия для оплавления для процесса пайки THR (сквозное отверстие с оплавлением)
- Соответствие стандартам VDE, UL, CSA и CQC
- Доступна в версиях с защитой от потока и герметичной для промывки
- Изоляция катушки класса F
RTD14012 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Case/Package | DIP |
| Current Rating | 16 A |
| Contacts Type | SPDT |
| Power Consumption | 400 mW |
| Contact Current Rating | 16.0 A |
| Coil Voltage | 12 VDC |
| Coil Current | 33.3 mA |
| Coil Power (DC) | 400 mW |
| Coil Resistance | 360 Ω |
| Coil Voltage (DC) | 12 V |
| Switching Current (Max) | 16 A |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Show | |
| Size-Length | 29 mm |
| Size-Width | 12.7 mm |
| Size-Height | 15.7 mm |
| Contact Material | Silver Nickel |
| Weight | 10.0 g |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Unknown |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
