RW1A030APT2CR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Case/Package	SOT-563-6
Number of Positions	6 Position
Drain to Source Resistance (on) (Rds)	0.03 Ω
Polarity	P-Channel
Power Dissipation	700 mW
Threshold Voltage	1 V
Drain to Source Voltage (Vds)	12 V
Rise Time	30 ns
Input Capacitance (Ciss)	2700pF @6V(Vds)
Input Power (Max)	700 mW
Fall Time	75 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	700mW (Ta)
	Show
Operating Temperature	150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
