Description

Never worry about unexpected ESD again from implementing this tvs SM36T1G ESD protection device manufactured from ON Semiconductor. This ESD diode has a maximum ESD protection device voltage of ±15@Air Gap/±8@Contact Disc kV. This device"s maximum clamping voltage is 60 V. This ESD diode has an operating temperature range of -55 °C to 150 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its capacitance value is 45(Typ) pF. It is made in a dual common anode|single configuration.

Show

SM36T1G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-23-3
Operating Voltage	36 V
Capacitance	45 pF
Power Rating	300 W
Breakdown Voltage	40 V
Number of Positions	3 Position
Power Dissipation	300 mW
Clamping Voltage	60 V
Max Repetitive Reverse Voltage (Vrrm)	36V
Test Current	1 mA
Max Breakdown Voltage	46.95 V
Peak Pulse Power	300 W
Min Breakdown Voltage	40 V
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Junction Temperature	-55℃ ~ 150℃
Power Dissipation (Max)	300 mW
	Show
Size-Length	2.9 mm
Size-Width	1.3 mm
Size-Height	1 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
Minimum Packing Quantity	3000
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
