Image is for your reference only,please check specifications for details
- SN74AUC1G79DCKR - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC15056504
-
Category:Flip Flop IC
-
Package:SC-70-5
-
Datasheet:Datasheet 3D Model
-
Description:Flip-Flop, Non Inverted, Positive Edge, 74AUC1G79, D, 1.8ns, 275MHz, 9mA, SC-70
-
Stock Locations:
-
Availability:269 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.27
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- This single positive-edge-triggered D-type flip-flop is operational at 0.8-V to 2.7-V VCC, but is designed specifically for 1.65-V to 1.95-V VCC operation.
- When data at the data (D) input meets the setup time requirement, the data is transferred to the Q output on the positive-going edge of the clock pulse. Clock triggering occurs at a voltage level and is not directly related to the rise time of the clock pulse. Following the hold-time interval, data at the D input can be changed without affecting the levels at the outputs.
- NanoFree™ package technology is a major breakthrough in IC packaging concepts, using the die as the package.
- This device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.
SN74AUC1G79DCKR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 5 Pin |
| Case/Package | SC-70-5 |
| Frequency | 275 MHz |
| Supply Voltage (DC) | 2.70 V, 2.70 V (max) |
| Number of Outputs | 1 Output |
| Output Current | 9 mA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Clock Speed | 275 MHz |
| Number of Bits | 1 Bit |
| Propagation Delay Max (tpd) | 1.30 ns, 1.80 ns |
| Polarity | Non-Inverting |
| Number of Gates | 1 Gate |
| Input Capacitance | 2.5 pF |
| Number of Inputs | 1 Input |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 0.8V ~ 2.7V |
| Supply Voltage (Max) | 2.7 V |
| Supply Voltage (Min) | 0.8 V |
| Show | |
| Size-Length | 2.15 mm |
| Size-Width | 1.4 mm |
| Size-Height | 1 mm |
| Operating Temperature | -40℃ ~ 85℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
