Description

The STTH2R02U is an Ultra-fast Recovery Diode especially suited for switching mode base drive and transistor circuits. It is intended for use in low voltage, high frequency inverters, free-wheeling and polarity protection.
Planar Pt doping technology
Very low conduction losses
Negligible switching losses
Low forward and reverse recovery times
High junction temperature

Show

STTH2R02U Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	DO-214AA
Voltage Rating (DC)	200 V
Current Rating	2.00 A
Output Current	≤2.00 A
Load Current	2 A
Forward Voltage	1V @2A
Polarity	Standard
Thermal Resistance	30℃/W (RθJC)
Reverse recovery time	30 ns
Forward Current	2 A
Max Forward Surge Current (Ifsm)	180 A
Maximum Forward Voltage (Max)	1 V
Forward Current (Max)	2 A
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	175℃ (Max)
Junction Temperature (Max)	175 ℃
	Show
Size-Length	4.6 mm
Size-Width	3.95 mm
Size-Height	2.45 mm
Operating Temperature	-65℃ ~ 175℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
