TLE6240GP - Infineon
Manufacturer:
Infineon
ManyChip's Part#:
MC8197858
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
PG-DSO-36
Datasheet:
Datasheet 3D Model
Description:
INFINEON TLE6240GP Power Load Switch, Low Side, Active High, Active Low, 16Outputs, 5.5V, 4.5A, SOIC-36
Stock Locations:
Availability:
827 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 7.4

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TLE6240GP is a 16-fold low-side Switch in Smart Power Technology (SPT) with a Serial Peripheral Interface (SPI) and 16 open drain DMOS output stages. The TLE6240GP is protected by embedded protection functions. The output stages are controlled via SPI Interface. Additionally 8 channels can be controlled direct in parallel for PWM applications. Therefore the TLE6240GP is particularly suitable for engine management and powertrain systems, safety and body applications.
Short-circuit protection
Overtemperature protection
Overvoltage protection
16-bit serial data input and diagnostic output
Direct parallel control of eight channels for PWM applications
Parallel inputs high or low active programmable
General fault flag
Low quiescent current
Compatible with 3V microcontrollers
Green product
AEC qualified

Show

TLE6240GP Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	36 Pin
Case/Package	PG-DSO-36
Number of Outputs	16 Output
Input Voltage (DC)	5.50 V
Output Current	500 mA
Supply Current	5 mA
Number of Positions	36 Position
Power Dissipation	3.3 W
Output Current (Min)	0.5 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	3300 mW
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
Input Voltage	5.5 V
	Show
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
