- TPS62000SHKK - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC77174996
-
Category:DC to DC Converter
-
Package:CFP-10
-
Datasheet:Datasheet 3D Model
-
Description:Conv DC-DC 2V to 5.5V Step Down Single-Out 0.8V to 5.5V 0.3A 10Pin CFPAK Tube
-
Stock Locations:
-
Availability:260 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 274.02
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Adjust the voltage level of your devices with this step down TPS62000SHKK DC to DC converter from Texas Instruments. This converter"s single output can produce a current up to 0.3 A. With a small input voltage of 2 V and a max of 5.5 V, this will supply sufficient power to your circuit. With an adjustable output that has a voltage of 0.8 to 5.5 V, this is power management at its best. This converter is 85(typ) % efficient. At a load regulation of 0.6%(Typ) and line regulation of 0.05%/V(Typ) your circuit is capable of maintaining a constant voltage level at your output. Its switching regulator has a frequency of 500 to 1000 kHz. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This converter has an operating temperature range of -55 °C to 210 °C.
TPS62000SHKK Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 10 Pin |
| Case/Package | CFP-10 |
| Number of Outputs | 1 Output |
| Output Voltage | 0.8V ~ 5.5V |
| Output Current | 300 mA |
| Quiescent Current | 50.0 µA |
| Number of Regulated Outputs | 1 Output |
| Switching Frequency | 750 kHz |
| Topology | Buck |
| Input Voltage (Max) | 5.5 V |
| Input Voltage (Min) | 2 V |
| Output Voltage (Max) | 5.5 V |
| Output Voltage (Min) | 0.8 V |
| Output Current (Max) | 0.3 A |
| Operating Temperature (Max) | 210 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Supply Voltage | 2 V |
| Input Voltage | 2 V |
| Show | |
| Size-Width | 6.35 mm |
| Operating Temperature | -55℃ ~ 210℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
