Description
- Non-Isolated PoL Module DC DC Converter 1 Output 1.2 ~ 6V 2.5A 4.5V - 28V Input
TPSM84209RKHT Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 9 Pin |
| Case/Package | QFN-9 |
| Power Rating | 15 W |
| Number of Outputs | 1 Output |
| Output Voltage | 1.2V ~ 6V |
| Output Current | 2.5 A |
| Number of Positions | 9 Position |
| Switching Frequency | 923 kHz |
| Input Voltage (Max) | 28 V |
| Input Voltage (Min) | 4.5 V |
| Output Voltage (Max) | 6 V |
| Output Voltage (Min) | 1.2 V |
| Output Current (Max) | 2.5 A |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Input Voltage | 4.5V ~ 28V |
| Show | |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status |
