Description
- Create your system design with this bicmos advanced phase shift resonant s UCC2895DW soft switching PWM controller manufactured by Texas Instruments, it uses soft switching to consume less power. This soft switching controller has 4 outputs. Its output produces a current of 100(Max) mA. Its switching regulator has a frequency of 1000 kHz. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This soft switching controller has an operating temperature range of -40 °C to 85 °C. This soft switching controller"s maximum duty cycle is 100 %. This device has a minimum operating supply voltage of 10 V and a maximum of 16.5 V.
UCC2895DW Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 20 Pin |
| Case/Package | SOIC-20 |
| Frequency | 1 MHz |
| Supply Voltage (DC) | 10.0V (min) |
| Number of Outputs | 4 Output |
| Output Voltage | 250 mV |
| Output Current | 100 mA |
| Supply Current | 5.00 mA |
| Power Dissipation | 650 mW |
| Number of Regulated Outputs | 4 Output |
| Rise Time | 20 ns |
| Switching Frequency | 1000 kHz |
| Topology | Full-Bridge |
| Duty Cycle | 100 % |
| Maximum Duty Cycle | 100 % |
| Fall Time | 20 ns |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 650 mW |
| Supply Voltage | 10V ~ 16.5V |
| Supply Voltage (Max) | 16.5 V |
| Supply Voltage (Min) | 10 V |
| Input Voltage | 10V ~ 16.5V |
| Show | |
| Size-Length | 12.8 mm |
| Size-Width | 7.52 mm |
| Size-Height | 2.35 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
