Description

Silicon PNP epitaxial type high voltage control applications plasma display, nixie tube driver applications cathode ray tube brightness control applications high voltage； low saturation voltage； small collector output capacitance； complementary to 2sc4497

Show

2SA1721 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Case/Package	S-Mini
Polarity	PNP
Breakdown Voltage (Collector to Emitter)	300 V
Continuous Collector Current	0.1A
Power Dissipation (Max)	150 mW
	Show
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
