Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 3 Pin |
Case/Package | SC-85 |
Frequency | 350 MHz |
Power Rating | 0.2 W |
Number of Positions | 3 Position |
Polarity | NPN |
Power Dissipation | 200 mW |
Breakdown Voltage (Collector to Emitter) | 50 V |
Continuous Collector Current | 0.1A |
hFE Min | 120 |
hFE Max | 560 |
Input Power (Max) | 200 mW |
DC Current Gain (hFE) | 120 |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -55 ℃ |
Power Dissipation (Max) | 200 mW |
Show | |
Size-Length | 2.1 mm |
Size-Width | 1.35 mm |
Size-Height | 1 mm |
Operating Temperature | 150℃ (TJ) |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
