Description

The 74HC4017N is a Johnson decade Counter with 10 decoded outputs (Q0 to Q9), an output from the most significant flip-flop (Q5-9), two clock inputs (CP0 and CP1) and an overriding asynchronous master reset input (MR). The counter is advanced by either a low-to-HIGH transition at CP0 while CP1 is low or a high-to-low transition at CP1 while CP0 is high. When cascading counters, the Q5-9 output, which is low while the counter is in states 5, 6, 7, 8 and 9, can be used to drive the CP0 input of the next counter. A high on MR resets the counter to zero independent of the clock inputs. Automatic code correction of the counter is provided by an internal circuit following any illegal code the counter returns to a proper counting mode within 11 clock pulses. Inputs include clamp diodes. This enables the use of current limiting resistors to interface inputs to voltages in excess of VCC.
CMOS input level
ESD protection HBM JESD22-A114E exceeds 2000V
ESD sensitive device, take proper precaution while handling the device.

Show

74HC4017N Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP
Supply Voltage (DC)	5.00 V, 6.00 V (max)
Number of Positions	16 Position
Clock Speed	83 MHz
Number of Bits	5 Bit
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	6 V
Supply Voltage (Min)	2 V
	Show
Size-Length	19.5 mm
Size-Width	6.48 mm
Size-Height	4.2 mm
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
