Image is for your reference only,please check specifications for details
- 76SB08ST - Grayhill
-
Manufacturer:Grayhill
-
ManyChip's Part#:MC8390245
-
Category:DIP Switch, SIP Switch
-
Package:DIP
-
Datasheet:Datasheet 3D Model
-
Description:GRAYHILL 76SB08ST DIP / SIP Switch, Raised Rocker, 8Circuits, SPST, Through Hole, 76 Series, DIP Sealed, 30VDC
-
Stock Locations:
-
Availability:266 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.84
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The 76SB08ST is a single-pole single-throw (SPST) 8-position through-hole DIP Sealed Switch with raised rocker. The 76 series switch has spring and ball contact.
- Tape sealed base standard
76SB08ST Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Case/Package | DIP |
| Pin Pitch | 2.54 mm |
| Voltage Rating (DC) | 30 V |
| Actuator Type | Rocker |
| Current Rating | 150 mA |
| Insulation Resistance | 5000 MΩ |
| Capacitance | 5.00 pF |
| Orientation | Vertical |
| Contacts Type | SPST |
| Number of Circuits | 8 Circuit |
| Number of Positions | 8 Position |
| Contact Resistance | 30 mΩ |
| Contact Current Rating | 150mA @24VDC |
| Current Rating (Max) | 0.15A @30VDC |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Voltage Rating | 30 VDC |
| Voltage Rating (DC Max) | 30 V |
| Show | |
| Size-Length | 22.4 mm |
| Size-Width | 9.65 mm |
| Size-Height | 8 mm |
| Lead Length | 3.96 mm |
| Contact Material | Copper Alloy |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2016/06/20 |
| HTS Code | 8536509060 |
| ECCN Code | EAR99 |
