Image is for your reference only,please check specifications for details

AD8045ARDZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC493940
Category:
Operational Amplifier, OP Amp IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8045ARDZ Operational Amplifier, Single, 1 Amplifier, 1GHz, 1350V/µs, 3.3V to 12V, SOIC, 8Pins
Stock Locations:
Availability:
219 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.81

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8045ARDZ is an Ultralow Distortion High Speed Operational Amplifier ideal solution in a variety of applications including ultrasound, ATE, active filters and ADC drivers. The AD8045 features a low distortion pinout for the LFCSP, which improves second harmonic distortion and simplifies the layout of the circuit board. It has 1GHz bandwidth, 1350V/µs slew rate and settles to 0.1% in 7.5ns. With a wide supply voltage range (3.3 to 12V) and low offset voltage (200µV), the AD8045 is an ideal candidate for systems that require high dynamic range, precision and high speed.
Ultralow distortion
Low noise
High speed
7.5ns Settling time to 0.1%
Standard and low distortion pinout
15mA Supply current
1mV Maximum offset voltage
ESD sensitive device, take proper precaution while handling the device.

Show

AD8045ARDZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	5.00 V
Output Current	55mA @5V
Supply Current	16 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	91 dB
Input Capacitance	1.30 pF
Bandwidth	1 GHz
Slew Rate	1.35 kV/μs
Gain Bandwidth Product	400 MHz
Input Impedance	3.60 MΩ
Gain	1.00 dB
Input Offset Voltage	200 µV
Input Bias Current	2 µA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	1 GHz
Minimum CMRR Range	78 dB
Supply Voltage	3.3V ~ 12V
Supply Voltage (Max)	12 V
Supply Voltage (Min)	3.3 V
	Show
Size-Length	4.9 mm
Size-Width	3.9 mm
Size-Height	1.65 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
