AD8307ANZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1305600
Category:
Amplifier, Buffer IC
Package:
PDIP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8307ANZ Logarithmic Amplifier, 1 Amplifier, 92dB, 500ns, DIP, 8Pins
Stock Locations:
Availability:
241 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 39.43

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8307ANZ is a 500MHz Monolithic Demodulating Logarithmic Amplifier based on the progressive compression (successive detection) technique, providing a dynamic range of 92dB to ±3dB law conformance and 88dB to a tight ±1dB error bound at all frequencies up to 100MHz. It is extremely stable and easy to use requiring no significant external components. A single-supply voltage of 2.7 to 5.5V at 7.5mA is needed. A fast acting CMOS-compatible control pin can disable the AD8307 to a standby current of 150µA. The amplifier is ideal for use in conversion of signal level to decibel form, transmitter antenna power measurement and receiver signal strength indication (RSSI) as well as low cost radar and sonar signal processing.
Highly stable scaling over-temperature
Fully differential DC-coupled signal path
100ns Power-up time
150µA Sleep current
±1dB Linearity
ESD sensitive device, take proper precaution while handling the device.

Show

AD8307ANZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	PDIP-8
Supply Current	8 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	22.5 mW
Quiescent Current	8.00 mA
Bandwidth	500 MHz
Input Offset Voltage	50 µV
Input Bias Current	25000 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	900 MHz
Supply Voltage	2.7V ~ 5.5V
Supply Voltage (Max)	5V ~ 7V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	9.27 mm
Size-Width	7.24 mm
Size-Height	3.43 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
