Image is for your reference only,please check specifications for details
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Product Details
- The ADP7182 is a CMOS, low dropout (LDO) linear regulator that operates from −2.7 V to −28 V and provides up to −200 mA of output current. This high input voltage LDO is ideal for regulation of high performance analog and mixed signal circuits operating from −27 V down to −1.2 V rails. Using an advanced proprietary architecture, it provides high power supply rejection and low noise, and achieves excellent line and load transient response with a small 2.2 μF ceramic output capacitor.
- The ADP7182 is available in fixed output voltage and an adjustable version that allows the output voltage to range from −1.22 V to −VIN \+ VDO via an external feedback divider.
- The following fixed output voltages are available from stock: −5 V (3 mm × 3 mm LFCSP), −1.8 V, −2.5 V, −3 V, −5 V (TSOT), −1.2 V, −1.5 V, −2.5 V, −5 V (2 mm × 2 mm LFCSP). Additional voltages are available by special order.
- The ADP7182 regulator output noise is 18 μV rms independent of the output voltage. The enable logic is capable of interfacing with positive or negative logic levels for maximum flexibility.
- The ADP7182 is available in 5-lead TSOT, 6- and 8-lead LFCSP packages for a small, low profile footprint.
- Applications
- Regulation to noise sensitive applications
- Analog-to-digital converter (ADC) and digital-to-analog converter (DAC) circuits, precision amplifiers
- Communications and infrastructure
- Medical and healthcare
- Industrial and instrumentation
- ### Features and Benefits
- Low noise: 18 μV rms
- Power supply rejection ratio (PSRR): 66 dB at 10 kHz at VOUT = −3 V
- Positive or negative enable logic
- Stable with small 2.2 μF ceramic output capacitor
- Input voltage range: −2.7 V to −28 V
- Maximum output current: −200 mA
- Low dropout voltage: −185 mV at −200 mA load
- Initial accuracy: ±1%
- Accuracy over line, load, and temperature
- +2% maximum/−3% minimum
- Low quiescent current, IGND = −650 μA with −200 mA load
- Low shutdown current: −2 μA
- Adjustable output from −1.22 V to −VIN \+ VDO
- Current-limit and thermal overload protection
- 6- and 8-lead LFCSP and 5-lead TSOT
- Supported by ADIsimPower tool
ADP7182 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Show | |
| Product Lifecycle Status | Recommended for New Designs |
