ICL7611DCPAZ - Intersil
Manufacturer:
Intersil
ManyChip's Part#:
MC57603538
Category:
Operational Amplifier, OP Amp IC
Package:
DIP-8
Datasheet:
Datasheet 3D Model
Description:
1.4MHz, Low Power CMOS Operational Amplifiers; PDIP8, SOIC8; Temp Range: 0° to 70°
Stock Locations:
Availability:
2,260 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.28

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ICL7611DCPAZ is a low power CMOS Operational Amplifier. This device provides the designer with high performance operation at low supply voltages and selectable quiescent currents and an ideal design tool when ultra low input current and low power dissipation are desired. A unique quiescent current programming pin allows setting of standby current with no external components. This results in power consumption as low as 20µW. The inputs are internally protected. Outputs are fully protected against short circuits to ground or to either supply. Because of the low power dissipation, junction temperature rise and drift are quite low. Applications utilizing these features may include stable instruments, extended life designs or high density packages.
±1 to ±8V Wide operating voltage range
10¹²R High input impedance
20µW Programmable power consumption
1pA (typical) Input current lower than BIFETs
V+ and V- Output voltage swing
Input common mode voltage range greater than supply rails
Stresses above those listed in absolute maximum ratings may cause permanent damage to the device.

Show

ICL7611DCPAZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Voltage (DC)	5.00 V
Supply Current	1 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	60 dB
Bandwidth	1.4 MHz
Slew Rate	1.60 V/μs
Gain Bandwidth Product	1.4 MHz
Thermal Shutdown	No
Input Offset Voltage	15 mV
Input Bias Current	1 pA
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Gain Bandwidth	1.4 MHz
Minimum CMRR Range	60 dB
Supply Voltage	1.8 VDC
Supply Voltage (Max)	16 V
Supply Voltage (Min)	2 V
	Show
Size-Length	10.16 mm
Size-Width	7.11 mm
Size-Height	4.95 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
