MAX3232ECWE+ - Maxim Integrated
Manufacturer:
Maxim Integrated
ManyChip's Part#:
MC20054110
Category:
Interface IC, Interface Controller
Package:
SOIC-16
Datasheet:
Datasheet 3D Model
Description:
MAXIM INTEGRATED PRODUCTS MAX3232ECWE+ Low Power, RS232 Transmitter/Receiver, 2 Drivers/2 Receivers(mAX232 compatible), SOIC-16
Stock Locations:
Availability:
53 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.31

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The MAX3232ECWE+ is a True RS-232 Transceiver for cell-phone data cables. The MAX3232E +3.0V-powered EIA/TIA-232 and V.28/V.24 communications interface devices feature low power consumption, high data-rate capabilities and enhanced electrostatic-discharge (ESD) protection. The enhanced ESD structure protects all transmitter outputs and receiver inputs to ±15kV using IEC 1000-4-2 air-gap discharge and ±15kV using the human body model. A proprietary low-dropout transmitter output stage delivers true RS-232 performance from a +3.0 to +5.5V power supply, using an internal dual charge pump. The charge pump requires only four small 0.1µF capacitors for operation from a +3.3V supply. Each device guarantees operation at data rates of 250kbps while maintaining RS-232 output levels. The MAX3232E have two receivers and two transmitters.
ESD sensitive device, take proper precaution while handling the device.

Show

MAX3232ECWE+ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	5.50 V, 5.50 V (max)
Supply Current	0.3 mA
Number of Positions	16 Position
Data Rate	250 kbps
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	Show
Size-Length	10.5 mm
Size-Width	7.6 mm
Size-Height	2.35 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
