Description

Use ON Semiconductor"s NVTFS4823NTAG power MOSFET to switch quickly between different electronic signals with ease. Its maximum power dissipation is 3100 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This MOSFET transistor has a minimum operating temperature of -55 °C and a maximum of 175 °C. This N channel MOSFET transistor operates in enhancement mode.

Show

NVTFS4823NTAG Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	WDFN-8
Halogen Free Status	Halogen Free
Drain to Source Resistance (on) (Rds)	0.0081 Ω
Polarity	N-Channel
Power Dissipation	3.1 W
Threshold Voltage	2.5 V
Drain to Source Voltage (Vds)	30 V
Rise Time	22 ns
Input Capacitance (Ciss)	750pF @12V(Vds)
Fall Time	4 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	3.1W (Ta), 21W (Tc)
	Show
Size-Length	3.15 mm
Size-Width	3.15 mm
Size-Height	0.75 mm
Operating Temperature	-55℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
