Description

Implement this versatile PNP ZXTP2025FTA GP BJT from Diodes Zetex into an electronic circuit to be used as a current or voltage-controlled switch or amplifier. This bipolar junction transistor"s maximum emitter base voltage is 7 V. Its maximum power dissipation is 1560 mW. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It has a maximum collector emitter voltage of 50 V and a maximum emitter base voltage of 7 V. This bipolar junction transistor has a minimum operating temperature of -55 °C and a maximum of 150 °C.

Show

ZXTP2025FTA Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-23-3
Frequency	190 MHz
Voltage Rating (DC)	-50.0 V
Current Rating	-5.00 A
Polarity	PNP
Power Dissipation	1.56 W
Breakdown Voltage (Collector to Emitter)	50 V
Continuous Collector Current	5A
hFE Min	200 @500mA, 2V
Input Power (Max)	1.2 W
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	1560 mW
	Show
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
