- Кремниевый эпитаксиальный транзистор NPN для низкочастотных усилителей мощности и переключателей средней скорости. ОСОБЕННОСТИ:
- Высокая допустимая сила тока
- Низкое напряжение насыщения коллектора
- Комплементарный транзистор с 2SB1572
2SD2403 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Case/Package | SOT-89 |
| 集电极-基极反向击穿电压V(BR)CBOCollector-Base Voltage(VCBO) | 80V |
| 集电极-发射极反向击穿电压V(BR)CEOCollector-Emitter Voltage(VCEO) | 60V |
| 集电极连续输出电流ICCollector Current(IC) | 3A |
| 截止频率fTTranstion Frequency(fT) | 130MHz |
| 直流电流增益hFEDC Current Gain(hFE) | 200~400 |
| 管压降VCE（sat）Collector-Emitter Saturation Voltage | 150mV/0.15V |
| 耗散功率PcPower Dissipation | 2W |
