AD736AQ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC603400
Category:
Operational Amplifier, OP Amp IC
Package:
CDIP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD736AQ RMS to DC Converter, Low Power, 0.3%, 460kHz, -40℃, 85℃, DIP, 8Pins
Stock Locations:
Availability:
232 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 8.04

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

GENERAL DESCRIPTION
The AD736 is a low power, precision, monolithic true rms-to dc converter. It is laser trimmed to provide a maximum error of ±0.3 mV ± 0.3% of reading with sine wave inputs. Furthermore, it maintains high accuracy while measuring a wide range of input waveforms, including variable duty-cycle pulses and triac (phase)-controlled sine waves. The low cost and small size of this converter make it suitable for upgrading the performance of non-rms precision rectifiers in many applications. Compared to these circuits, the AD736 offers higher accuracy at an equal or lower cost.

Show

AD736AQ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	CDIP-8
Output Current	2 mA
Supply Current	160 µA
Input Current	0.2 mA
Power Dissipation	200 mW
Bandwidth	460 kHz
Input Voltage (Max)	0.2 V
Output Voltage (Max)	1.6 V
Output Current (Max)	2 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	190kHz, 460kHz
Power Dissipation (Max)	200 mW
Accuracy	0.3 %
Input Voltage	200 V
	Show
Size-Length	10.29 mm
Size-Width	7.87 mm
Size-Height	3.56 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
