AD8646ARMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC743988
Category:
Operational Amplifier, OP Amp IC
Package:
MSOP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8646ARMZ Operational Amplifier, Dual, 2 Amplifier, 24MHz, 11V/µs, 2.7V to 5.5V, MSOP, 8Pins
Stock Locations:
Availability:
11 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 8.86

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8646ARMZ is a 24MHz Dual Rail-to-rail Input/Output Amplifier features low offset voltage, wide signal bandwidth, low input voltage and low current noise. The combination of 24MHz bandwidth, low offset, low noise and very low input bias current makes this amplifier useful in a wide variety of applications. Filters, integrators, photodiode amplifiers and high impedance sensors all benefit from the combination of performance features. AC applications benefit from the wide bandwidth and low distortion. The AD8646 offers high output drive capability, which is excellent for audio line drivers and other low impedance applications. Applications include portable and low powered instrumentation, audio amplification for portable devices, portable phone headsets, barcode scanners and multipole filters. The ability to swing rail to rail at both the input and output enables designers to buffer CMOS ADCs, DACs, ASICs and other wide output swing devices in single-supply systems.
2.5mV Maximum offset voltage
Single-supply operation
8nV/√Hz Noise
120mA Short-circuit output current
No phase reversal
1pA Input bias current
2mA Maximum supply current per amplifier
Unity-gain stable
ESD sensitive device, take proper precaution while handling the device.

Show

AD8646ARMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Supply Current	1.5 mA
Number of Circuits	2 Circuit
Number of Positions	8 Position
Common Mode Rejection Ratio	84.0 dB
Input Capacitance	6.70 pF
Bandwidth	24 MHz
Slew Rate	11.0 V/μs
Gain Bandwidth Product	24 MHz
Input Offset Voltage	600 µV
Input Bias Current	0.3 pA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	24 MHz
Minimum CMRR Range	67 dB
Supply Voltage	2.7V ~ 5.5V
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
