Description

Product Details
The HMC8205BF10 is a gallium nitride (GaN) broadband power amplifier delivering 45.5 dBm (35 W) with 38% power added efficiency (PAE) across an instantaneous bandwidth of 0.3 GHz to 6 GHz. No external matching is required to achieve full band operation. Additionally, no external inductor is required to bias the amplifier. Also, dc blocking capacitors for the RFIN and RFOUT pins are integrated into the HMC8205BF10.
The HMC8205BF10 is ideal for pulsed or continuous wave (CW) applications, such as military jammers, wireless infrastructure, radar, and general-purpose amplification.
The HMC8205BF10 amplifier is a 10-lead ceramic leaded chip carrier (LDCC).
**Applications**
Military jammers
Commercial and military radar
Power amplifier stage for wireless infrastructure
Test and measurement equipment
### Features and Benefits
High PSAT: 46 dBm
High power gain: 20 dB
High PAE: 38%
Instantaneous bandwidth: 0.3 GHz to 6 GHz
Supply voltage: VDD = 50 V at 1300 mA
10-lead LDCC package
