Image is for your reference only,please check specifications for details
- LADN11 - Schneider Electric
-
Manufacturer:Schneider Electric
-
ManyChip's Part#:MC10162975
-
Category:Signal Relays
-
Datasheet:Datasheet 3D Model
-
Description:«Schneider Electric / Square D LADN11, блок вспомогательных контактов, 690 В переменного тока при частоте 25–400 Гц, 10 А, 1НО–1НК, фронтальное крепление...»
-
Stock Locations:
-
Availability:648 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 11.52
Updated at 01/11/2026 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- LADN11 является блоком вспомогательных контактов для использования с контакторами серий TeSys D и F.
- Конфигурация контактов: 1НО + 1НК
- Номинальное рабочее напряжение: 690 В переменного тока
- Минимальный ток коммутации: 5 мА при 17 В
- Клеммы с винтовым зажимом
- Соблюдение стандартов UL и CSA
- Мгновенная работа вспомогательных контактов
LADN11 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Screw Terminals |
| Number of Contacts | 2 Contact |
| Current Rating | 10 A |
| Contacts Type | DPST-NO |
| Coil Voltage | 120 V |
| Voltage Rating | 690 VAC |
| Show | |
| Size-Height | 47.0 mm |
| RoHS | Non-Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2014/06/16 |
