74HCT1G04GW - NXP
Manufacturer:
NXP
ManyChip's Part#:
MC128240675
Category:
Logic Control, Logic Gate IC
Package:
SOT-353
Datasheet:
Datasheet 3D Model
Description:
NXP 74HCT1G04GW Inverter, 74HCT1G04, 1Input, 2mA, 4.5V to 5.5V, SOT-353-5
Stock Locations:
Availability:
2,361 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.3

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The 74HCT1G04GW is a single Inverter with TTL input switching levels. Inputs include clamp diodes that enable the use of current limiting resistors to interface inputs to voltages in excess of VCC. The device features symmetrical output impedance and high noise immunity.
Low power dissipation
Balanced propagation delays
ESD protection - HBM JESD22-A114E exceeds 2000V, MM JESD22-A115-A exceeds 200V

Show

74HCT1G04GW Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	5 Pin
Case/Package	SOT-353
Supply Voltage (DC)	4.50V (min)
Output Current	2 mA
Number of Positions	5 Position
Number of Inputs	1 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	4.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	2.25 mm
Size-Width	1.35 mm
Size-Height	1 mm
Product Lifecycle Status	Unknown
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
