AD627ANZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC835436
Category:
Instrumentation Amplifier IC
Package:
DIP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD627ANZ Instrument Amplifier, 1 Amplifier, 200μV, 0.05V/µs, 80kHz, ± 1.1V to ± 18V, DIP
Stock Locations:
Availability:
278 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.54

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD627ANZ is an integrated micropower Instrumentation Amplifier delivers rail-to-rail output swing on single and dual (+2.2 to ±18V) supplies. The AD627 provides excellent AC and DC specifications while operating at only 85µA maximum. The AD627 offers superior flexibility by allowing the user to set the gain of the device with a single external resistor while conforming to the 8-lead industry-standard pinout configuration. With no external resistor, the AD627 is configured for a gain of 5. With an external resistor, it can be set to a gain of up to 1000. A wide supply voltage range (+2.2 to ±18V) and micropower current consumption make the AD627 a perfect fit for a wide range of applications. Single-supply operation, low power consumption and rail-to-rail output swing make the AD627 ideal for battery-powered applications.
Micropower, 85µA maximum supply current
Easy-to-use
Higher performance than discrete designs
Rail-to-rail output swing
High accuracy DC performance

Show

AD627ANZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Voltage (DC)	15.0 V
Supply Current	60 µA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	1.3 W
Common Mode Rejection Ratio	90 dB
Bandwidth	80 kHz
Slew Rate	50.0 mV/μs
Input Offset Voltage	200 µV
Input Bias Current	2 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	80 kHz
Power Dissipation (Max)	1300 mW
Minimum CMRR Range	77 dB
Supply Voltage (Max)	36 V
Supply Voltage (Min)	2.2 V
	Show
Size-Length	9.27 mm
Size-Width	6.35 mm
Size-Height	3.3 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
