ADE7953ACPZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC231650
Category:
Active Chip
Package:
LFCSP-28
Datasheet:
Datasheet 3D Model
Description:
Multifunction Metering IC I2C/SPI/UART Interface 28Pin LFCSP EP Tray
Stock Locations:
Availability:
279 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.66

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADE7953ACPZ is a Single-phase Multifunction Metering IC with neutral current measurement. It measures line voltage and current, calculates active, reactive and apparent energy, as well as instantaneous rms voltage and current. It incorporates three Σ-Δ ADCs with a high accuracy energy measurement core. The second input channel simultaneously measures neutral current and enables tamper detection and neutral current billing. The additional channel incorporates a complete signal path that allows a full range of measurements. Each input channel supports independent and flexible gain stages, making the device suitable for use with a variety of current sensors such as current transformers (CTs) and low value shunt resistors. Two on-chip integrators facilitate the use of Rogowski coil sensors. The ADE7953 provides access to on-chip meter registers via a variety of communication interfaces including SPI, I²C and UART.
High accuracy
Measures active, reactive and apparent energy, sampled waveform, current and voltage rms
Provides a second current input for neutral current measurement
Less than 0.1% error in active and reactive energy measurements over a dynamic range of 3000:1
Less than 0.2% error in instantaneous IRMS measurement over a dynamic range of 1000:1
Provides apparent energy measurement and instantaneous power readings
1.23kHz Bandwidth operation
Flexible PGA gain stage (up to x22)
